Material & Tool Sizes

This page contains tables & links to some useful material and tool dimensions:

Scroll Saw blade Selection Chart

Page 1

Page 2

Drill Sizes

A way better chart than the one below with metric sizes located at WoodCentral

Another drill chart.

Drill sizes

Biscuit Sizes

Size Dimensions mm Dimensions inches Notes
#00 (#FF) Uses a smaller cutter wheel
#0 47 x 15 x 4 mm ?” wide X 1¾” long
#10 53 x 19 x 4 mm ¾” wide X 2?” long
#20 56 x 23 x 4 mm 1″ wide X 2?” long

Standard Lumber Sizes

NOMINAL SIZE ACTUAL SIZE
1 X 1 3/4″ X 3/4″
1 X 3 3/4″ X 2 1/2″
1 X 4 3/4″ X 3 1/2″
1 X 6 3/4″ X 5 1/2″
1 X 8 3/4″ X 7 1/4″
1 X 10 3/4″ X 9 1/4″
1 X 12 3/4″ X 111/4″
2 X 2 1 1/2″ X 1 1/2″
2 X 4 1 1/2″ X 3 1/2″
2 X 6 1 1/2″ X 5 1/2″
2 X 8 1 1/2″ X 7 1/4″
2 X 10 1 1/2″ X 9 1/4″
2 X 12 1 1/2″ X 11 1/4″
